RTA30

Pubdate:2019-06-18Views:153




Brand:
Unit price: Negotiable
MOQ:
Total supply:
Delivery period: within 3 days from the date of payment by the buyer
Expires: Long-term effective

Product Detail


Microwave sensor integrated with driver, dimming(when person leave the detection area after hold time, lamp can keeps half brightness,for energy saving)
item size:dia.90*(36+12)mm,
Power supply: 180-240VAC
Power frequency: 50/60Hz
Installation sit: indoors, ceiling mounting
HF system: 5.8GHz CW radar, ISM band
Transmission power: <10mW
MAX Wattage: 20W
Detection angel: 360°, Reach: 3-10m(radii,adjust)
Time setting: 10s-10min, Light control: 10-50Lux  ,
Hold Time setting: 10s-10min,
dayLight sensor control: 10-50Lux ,
stand-by light: 0%,10%,20%,30%
Semi bright time: 24H,1min,30min,60min
OUTPUT:27-32V DC, MAX.600MA
Certificate:RED,RoHS
